Trek
2026 | Marlin 5 Gen 3
2026 | Marlin 5 Gen 3
Regular price
$929.99
Sale price
$929.99
Regular price
Shipping calculated at checkout.
SKU:TRE49590677E
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.
Canadian shipping charges:
- Sale bikes: $200
- Standard pedal bikes: $100
- Electric bikes: $200
- Fat bikes: $200
- Kid's bikes: $60
Insurance charge: 1.5% insured value
Visit our shipping page for more details
Bike Specifications
Bike Specifications
Specifications are subject to change without notice
Drivetrain
Cassette
Shimano LINKGLIDE LG300, 11-46, 9 speed
Chain
Shimano LG500
Rear derailleur
Shimano CUES U4000
Shifter
Shimano U4000, 9 speed
Brakes
Brake rotor
Shimano RT26, 6-bolt, 160mm
Brake type
Hydraulic disc
Cockpit
Grips tape
Trek Line Comp, nylon lock-on
Handlebars
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Pedals
VP-536 nylon platform
Saddle
Bontrager Verse Short, stainless steel rails
Seatpost
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Stem
Bontrager Comp, 31.8mm, 7 degree, 35mm length
Wheels
Front hub
Formula DC-20, alloy, 6-bolt, 100x5mm
Rear hub
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm
Rims
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
Spokes
14g stainless steel, black
Tires
Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.4''
Wheel size
27.5"
Suspension
Fork
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Fork brand
SR Suntour
Frame
Bottom bracket
Shimano, 73mm, threaded cartridge, 122.5mm spindle
Frame
Alpha Silver Aluminum, curved top tube, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew
Frame material
Aluminum
Headset
Semi-integrated, 1-1/8"
Seatpost
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Weight as spec d
M - 15.10 kg / 33.29 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
Share this product
Description
Description
Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. It features a trail-savvy frame with a suspension fork, 9-speed Shimano CUES shifting, and mounts for a rack and kickstand that make it an ideal choice for trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike.
Geometry Chart
Geometry Chart
Part Numbers
Part Numbers
| Size / Wheel Size | Mulsanne Blue | Miami Green/Dark Aquatic Fade | Fury Red |
|---|---|---|---|
| X-Small / 27.5" |
SKUTRE36573571E
VPNTrek_5337022
UPC197216263401
MPN5337022
|
SKUTRE49590677E
VPNTrek_5337029
UPC197216263470
MPN5337029
|
SKUTRE3163823D
VPNTrek_5337015
UPC197216263333
MPN5337015
|
| X-Small / 29" | — | — | — |
| Small / 27.5" |
SKUTRE35485686E
VPNTrek_5337023
UPC197216263418
MPN5337023
|
SKUTRE4835638E
VPNTrek_5337030
UPC197216263487
MPN5337030
|
SKUTRE30678206D
VPNTrek_5337016
UPC197216263340
MPN5337016
|
| Small / 29" | — | — | — |
| Medium / 27.5" | — | — | — |
| Medium / 29" |
SKUTRE34973621E
VPNTrek_5337024
UPC197216263425
MPN5337024
|
SKUTRE47320232E
VPNTrek_5337031
UPC197216263494
MPN5337031
|
SKUTRE29568418D
VPNTrek_5337017
UPC197216263357
MPN5337017
|
| Medium/Large / 27.5" | — | — | — |
| Medium/Large / 29" |
SKUTRE35186133E
VPNTrek_5337025
UPC197216263432
MPN5337025
|
SKUMAR409014753
VPNTrek_5337032
UPC197216263500
MPN5337032
|
SKUTRE30398743D
VPNTrek_5337018
UPC197216263364
MPN5337018
|
| Large / 27.5" | — | — | — |
| Large / 29" |
SKUTRE34455413E
VPNTrek_5337026
UPC197216263449
MPN5337026
|
SKUTRE47938952E
VPNTrek_5337033
UPC197216263517
MPN5337033
|
SKUTRE29184508D
VPNTrek_5337019
UPC197216263371
MPN5337019
|
| X-Large / 27.5" | — | — | — |
| X-Large / 29" |
SKUTRE35366368E
VPNTrek_5337027
UPC197216263456
MPN5337027
|
SKUTRE4897554E
VPNTrek_5337034
UPC197216263524
MPN5337034
|
SKUTRE30493406D
VPNTrek_5337020
UPC197216263388
MPN5337020
|
| XX-Large / 27.5" | — | — | — |
| XX-Large / 29" |
SKUTRE36880745E
VPNTrek_5337028
UPC197216263463
MPN5337028
|
— |
SKUTRE31143030D
VPNTrek_5337021
UPC197216263395
MPN5337021
|
Size Chart
Size Chart
Trek | Mountain
| Size | Size (cm) | Rider height (in) | Rider height (cm) | Inseam (in) | Inseam (cm) |
|---|---|---|---|---|---|
| X-Small | — | 4'9" - 5'1" | 145 - 155 cm | 27" - 29" | 69 - 73 cm |
| Small | — | 5'1" - 5'5" | 155 - 165 cm | 29" - 31" | 74 - 78 cm |
| Medium | — | 5'5" - 5'10" | 165 - 177 cm | 31" - 33" | 79 - 83 cm |
| Medium/Large | — | 5'8" - 5'11" | 173 - 180 cm | 32" - 34" | 81 - 86 cm |
| Large | — | 5'10" - 6'2" | 177 - 188 cm | 33" - 35" | 84 - 89 cm |
| X-Large | — | 6'2" - 6'5" | 188 - 195 cm | 35" - 36" | 89 - 91 cm |
| XX-Large | — | 6'5" - 6'8" | 195 - 203 cm | 36" - 38" | 91 - 97 cm |
