Fuel EX 8 is a dialed trail bike for riders who chase down rowdy descents and want a bike that's happy to pedal back to the top and do it again. It has a stout alloy frame and an upgraded Shimano XT drivetrain for smooth precise shifting. The 150mm Fox Rhythm fork makes easy work of rocks and roots while the Fox Float X shock keeps you in control. New in frame storage and adjustable geometry give you all the perks that come with the carbon model, but without the lofty price tag.
| SKU | Trek_36348 |
|---|---|
| Frame | Alpha Platinum Aluminum, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, downtube guard, shuttle guard |
| Frame | , ABP, UDH, Boost148, 140mm travel |
| Frame Material | Aluminum |
| Headset | Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible |
| Bottom Bracket | Shimano BB-MT501 BSA |
| Weight as Spec'd | M - 15.65 kg / 34.51 lbs (with TLR sealant, no tubes) |
| Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
| Brake - Brand | Shimano |
| Brake Type | Hydraulic disc |
| Brake | Shimano M6120 4-piston hydraulic disc // Shimano M6120 4-piston hydraulic disc |
| Brake Rotor | Shimano RT66, 6-bolt, 180mm // Shimano RT66, 6-bolt, 203mm |
| Handlebar | Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width |
| Stem | Bontrager Elite, 35mm, 0 degree, 45mm length |
| Grips | Bontrager XR Trail Elite, nylon lock-on |
| Saddle | Bontrager Arvada, hollow chromoly rails, 138 mm width |
| Seatpost | TranzX JD-YSP39, 150 mm travel, internal routing, 34.9 mm |
| Drivetrain - Brand | Shimano |
| Rear Derailleur | Shimano XT M8100, long cage |
| Crank | Shimano Deore M6120, 30T ring, 55 mm chainline, 170 mm length |
| Shifter | Shimano XT M8100, 12 speed |
| Chainring Size - Max | 1x: 34T round, 32T oval, min 28T |
| Cassette | Shimano XT M8100, 10-51, 12 speed |
| Chain | Shimano SLX M7100, 12 speed |
| Fork - Brand | Fox |
| Fork | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel |
| Shock - Brand | Fox |
| Shock | Fox Performance Float X, 2-position damper, 185mm x 55mm |
| Wheel Size | 29" |
| Wheel - Front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29' / |
| Wheel - Rear | Bontrager Line Comp 30, High Strength 6000 Series Aluminum rim, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 29' |
| Tires | Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 29x2.50' |
| Tire Size | 29x2.50" |
| Skewer - Rear | Bontrager Switch thru axle, removable lever |
| Rim Strip | Bontrager TLR |
| Small Parts | Bontrager TLR sealant, 180 ml/6 oz |
| _shipping-groups | FBPY-SRXL |
| BS Product Type | Trail Dual Suspension |
| Restricted | At this time Trek restricts the shipment of their bicycles directly to consumers. Please reach out to us via Email, or our chat, to help complete your purchase. |
| Bike Type | Trail |
| Discipline | Mountain |
| Platform | Fuel |
