2024 | Revolt Advanced 2

Product Info

Rough roads, gravel or dirt. However you choose to roll, this bike does it all. The lightweight, smooth-riding composite frameset and adjustable wheelbase make it more capable than ever.

Fast and light: Advanced composite frame and fork save more than 160g compared to the previous model. Updated geometry includes a lower bottom bracket, longer reach and steeper head tube angle for improved acceleration and climbing.

Tuned compliance: Dropped seatstays with thin tubing absorbs road shocks and vibrations. D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain: A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling, or long for improved stability at speed. You can also choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or d

SKU	Giant \| 2024 \| Revolt Advanced 2
Frame	Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout
Bottom Bracket	FSA BB-AL86 or Shimano Press Fit
E-Bike System	N/A
Brake	Shimano GRX RX-410 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Lever	Shimano GRX RX-610 hydraulic
Handlebar	Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Stem	Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Grips	Stratus Lite 3.0
Saddle	Giant Approach
Seatpost	Giant D-Fuse, composite, 14mm offset
Front Derailleur	Shimano GRX RX-820
Rear Derailleur	Shimano GRX RX-821
Crankset	FSA Omega Modular AGX+, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Shifter	Shimano GRX RX-610, 2x12
Chain	KMC X12L-1
Fork	Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Shock	N/A
Tires	Maxxis Rambler/Ravager, 700x40c, tubeless
Hub - Rear	Giant alloy, 12mm thru-axle
Rims	Giant P-X2 Disc wheelset, alloy
Spokes	Sapim
Cassette	Shimano CS-HG710, 12-speed, 11x36
_shipping-groups	FBPY-SRXL
BS Product Type	Endurance Gravel
