Marlin 6 is the perfect ride for progressing your skills on the trails. Its updated slacker frame geometry makes it easier to control on descents while the upgraded suspension fork takes the edge off bumpy trails. Integrated rack and kickstand mounts make it easy to add accessories to this versatile steed.
| SKU | Trek_40962 |
|---|---|
| Frame | Alpha Silver Aluminum, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew |
| Frame Material | Aluminum |
| Headset | Semi-integrated, 1-1/8" |
| Bottom Bracket | FSA, 73 mm, threaded cartridge, 122.5 mm spindle |
| Weight as Spec'd | M - 14.50 kg / 31.97 lbs (with tubes) |
| Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
| Brake Type | Hydraulic disc |
| Brake Rotor | Tektro, 6-bolt, 160mm |
| Handlebar | Bontrager alloy, 31.8mm, 15mm rise, 750mm width |
| Stem | Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length |
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| Pedals | VP-536 nylon platform |
| Saddle | Bontrager Verse Short, stainless steel rails |
| Seatpost | Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
| Drivetrain - Brand | Shimano |
| Rear Derailleur | Shimano CUES U6000 GS |
| Crank | FSA Alpha Drive, 30T, 175mm length |
| Shifter | Shimano U6000, 10 speed |
| Cassette | Shimano CUES LG300, LINKGLIDE, 11-48, 10 speed |
| Chain | Shimano LG500 |
| Fork - Brand | RockShox |
| Fork | RockShox Judy, coil spring, preload, TurnKey lockout, 46mm offset for 29' wheel, 100mm QR, 100mm travel |
| Wheel Size | 29" |
| Wheel - Front | / |
| Tires | Maxxis Ardent Race, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.35" |
| Tire Size | 29x2.35" |
| Hub - Front | Formula DC-20, alloy, 6-bolt, 100 mm ThruSkew |
| Hub - Rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer - Rear | 173x5mm QR |
| Rims | Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, Presta valve |
| _shipping-groups | ACYP-ECY |
| BS Product Type | Trail Hardtails |
| Restricted | At this time Trek restricts the shipment of their bicycles directly to consumers. Please reach out to us via Email, or our chat, to help complete your purchase. |
| Bike Type | Trail |
| Discipline | Mountain |
| Platform | Marlin |
