Rail+ 8 is an alloy enduro e-bike that packs in what you want most for big adventures. It comes equipped with a Bosch Performance CX drive system with full power for crushing laps and big climbs while its massive battery takes you the distance. 160mm of front and rear travel make Rail+ super capable in the rough and rowdy, and adjustable geometry lets you customize it for how and where you ride.
| SKU | Trek_48474 |
|---|---|
| Frame | Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armor, Boost148, 12mm thru axle, 160mm travel |
| Frame Material | Aluminum |
| Headset | Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible |
| Weight as Spec'd | M - 25.08 kg / 55.3 lbs (with TLR sealant, no tubes) |
| Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
| Motor | Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC) |
| Battery | Bosch PowerTube 800Wh, smart system |
| E-Bike - Primary Battery Type | 800WH |
| Controller | Bosch System Controller BRC3100, smart system |
| Brake - Brand | SRAM |
| Brake Type | Hydraulic disc |
| Brake | SRAM DB 8 4-piston hydraulic disc // SRAM DB 8 4-piston hydraulic disc |
| Brake Rotor | SRAM CenterLine, 6-bolt, round edge, 200mm |
| Handlebar | Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width |
| Stem | Bontrager Elite, 35mm, 0 degree, 45mm length |
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| Pedals | VP-536 nylon platform |
| Saddle | Bontrager Verse P3, steel rails |
| Seatpost | Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 4500mm length |
| Drivetrain - Brand | Shimano |
| Rear Derailleur | Shimano XT M8100, long cage |
| Crank Arm | E*thirteen E*spec Plus, 160mm length |
| Shifter | Shimano SLX M7100, 12 speed |
| Cassette | Shimano Deore M6100, 10-51, 12 speed |
| Chain | Shimano SLX M7100, 12 speed |
| Fork - Brand | RockShox |
| Fork | RockShox ZEB Select, DebonAir spring, Charger RC damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 160mm travel |
| Shock - Brand | RockShox |
| Shock | RockShox Super Deluxe Select+ RT, 205mm x 65mm |
| Wheel Size | 27.5"/29" |
| Wheel - Front | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29' / |
| Wheel - Rear | Bontrager Line Comp 30, High Strength 6000 Series Aluminum rim, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 27.5' |
| Tires | Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50" // Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50" |
| Tire Size | 29x2.50" |
| Skewer - Rear | Bontrager Switch thru axle, removable lever |
| Small Parts | Bontrager TLR sealant, 180 ml/6 oz |
| _shipping-groups | ACYP-ECY |
| BS Product Type | Enduro Full Power Assist E-MTB |
