2026 | CheckOUT SL 5

$7,499.99
Available To Ship
Available For Pickup
View Store Details
Not Available
View Store Details
Low Stock
View Store Details

Product Info

Get lost Wildly fun, freakishly capable. The all-new CheckOUT is the best bike for everything from road-to-gravel-to-singletrack adventures to bikepacking the 2,745-mile Tour Divide. Designed to be faster than a mountain bike on paved roads and more capable than a rigid gravel bike on singletrack, this is the ideal rig for real adventurers who aren’t afraid to go way, way, way out there. CheckOUT SL 5 is an adventure-ready full suspension gravel bike for getting way, way out there. Its carbon frame delivers 55mm of rear travel from a RockShox SIDluxe IsoStrut shock, while a RockShox Rudy XL fork smooths rowdy roads and trails with 60mm of travel. It comes ready to explore with Bontrager Paradigm Comp wheels, a 12-speed Shimano GRX drivetrain, and TranzX dropper post.

SKU 2026 | CheckOUT SL 5
Frame Material Carbon
Bottom Bracket Praxis, T47 threaded, internal bearing
Weight as Spec'd ML - 12.74 kg / 28.09 lbs (with TLR sealant, no tubes)
Weight Limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
Brake Rotor Shimano CL800, centerlock, 160mm
Brake Rotor Size Max | 180mm front & rear
Handlebar Bontrager GR Checkout | S = 42cm | M = 44cm | ML,L = 46cm | XL = 48cm
Stem Bontrager Elite, 31.8mm, Blendr compatible, 7 degree | S,M = 60mm | ML,L = 70mm | XL = 80mm
Grips Bontrager Supertack Perf tape
Saddle Verse Short Comp, steel rails, 145mm width
Rear Derailleur Shimano GRX RX822, 51T max cog
Crank Shimano GRX RX610, 38T | S = 160mm | M,ML = 170mm | L,XL = 172.5mm
Shifter Shimano GRX RX820, 12 speed
Chainring Size - Max 1x | 38T
Cassette Shimano XT M8200, 10-51, 12 speed
Chain Shimano XT M8100, 12 speed
Fork RockShox Rudy XL Ultimate, Charger Race Day 2 Solo Air spring, tapered steerer, 45mm offset, 12x100mm thru axle, 60mm travel
Shock RockShox SIDluxe Ultimate 3P, 170mmx27.5mm
Tire Size - Max 56mm/2.20"
Wheel - Front Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Wheel - Rear Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, SRAM XD-R 12-speed freehub, 142x12 thru axle
Tires Bontrager Betasso RSL GX, Tubeless ready, aramid bead, 60 tpi, 700x50mm
Skewer - Rear Bontrager Switch chamfered thru axle, removable lever
Cargo Rack Checkout rear rack
_shipping-groups ACYP-ECY
BS Product Type Gravel Adventure
Discipline Gravel
Model Year 2026
Wheel Size 700C
Geo - Wheel Size 700C
