2026 | Fuel+ EX 8 Gen 2 - The Bike Shop

Product Info

Fuel+ EX 8 is a quiet and composed electric mountain bike built for tackling any trail. It all starts out with an Alpha NEXT Platinum aluminum frame that gives you a smooth boost thanks to TQ's HPR-60 motor. A Fox Performance suspension package (145mm rear, 150mm front) keeps handling confident in the rough, while SRAM's Eagle 70 transmission delivers the smooth-shifting advantage of T-Type at a pocket-friendly price. It's all wrapped up with 4-piston SRAM DB 8 hydraulic disc brakes for stopping power on the steeps.

SKU	Trek_56301
Frame	Alpha NEXT Platinum aluminum, removable battery, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel
Frame	145mm-160mm
Frame Material	Aluminum
Headset	FSA Orbit, sealed cartridge bearing, 1-1/8' top, 1.5' bottom, 1.5 crown
Weight as Spec'd	M - 21.08 kg / 46.48 lbs (with TLR sealant, no tubes)
Weight Limit	This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
Motor	TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
Battery	TQ 580Wh
E-Bike - Primary Battery Type	360WH
Brake - Brand	SRAM
Brake Type	Hydraulic disc
Brake	SRAM DB 8 4-piston hydraulic disc // SRAM DB 8 4-piston hydraulic disc
Brake Rotor	SRAM Centerline 2.0, 6-bolt, 200mm
Brake Rotor Size	Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer
Handlebar	Race Face Turbine, alloy, 35mm, 40mm rise, 780mm width
Stem	Bontrager Elite, 35mm, 0 degree, 45mm length
Grips	Trek Line Comp, nylon lock-on
Saddle	Bontrager Verse Short, stainless steel rails
Seatpost	Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length
Drivetrain - Brand	SRAM
Rear Derailleur	SRAM Eagle 70, T-Type
Crank	SRAM EAGLE 70, 160mm length
Shifter	SRAM Eagle 70, 12 speed
Chainring	SRAM T-Type, 32T, alloy
Cassette	SRAM Eagle XS-1270, T-Type,10-52, 12 speed
Chain	SRAM Eagle 70, T-Type, 12 speed
Fork - Brand	Fox
Fork	Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt X axle, 150mm travel
Shock - Brand	Fox
Shock	Fox Performance Float X, 2-position damper, 205mm x 60mm
Wheel Size	27.5"/29"
Tires	Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50" // Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50"
Tire Size	29x2.50"
Hub - Front	Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub - Rear	Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano freehub, Boost148, 12mm thru axle
Skewer - Rear	Bontrager Switch thru axle, removable lever
Rims	Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve // Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve
Rim Strip	Bontrager TLR // Bontrager TLR
Small Parts	Bontrager TLR sealant, 180 ml/6 oz
_shipping-groups	ACYP-ECY
BS Product Type	Trail - Light Assist
Discipline	Mountain
Model Year	2026
DG code	Yes
