2026 | Fuel+ EX 9.7 Gen 2

$10,999.99
Available To Ship
Available For Pickup
View Store Details
Not Available
View Store Details
Low Stock
View Store Details

Product Info

Fuel+ EX 9.7 is a carbon e-MTB that packs in adaptability for any kind of trail and any style of riding. It's equipped with the smooth and quiet boost of TQ's HPR60 motor with a 580Wh battery for bigger rides. You get the perfect balance of price and performance, with components like a Fox Rhythm 36 fork, Fox Performance Float X shock, SRAM Eagle T-Type shifting, and a Bontrager Line dropper post.


Adapt, rip, repeat

    Only you can define your perfect trail bike — that's why Fuel is available in three adjustability-packed configurations. Get do-it-all capability with EX, go pop-happy with MX, or charge through it all with LX.


Adjustable leverage rate

    Want more bottom-out resistance without giving up small-bump sensitivity? Flip the chip in the lower shock mount for a more progressive leverage rate.


Zero stack integrated headset

    With a ZS standard headset, you've got tons of options for aftermarket upgrades, including angle adjust or anodized colors.


Storage and accessory mounts

    Stash ride essentials with in-frame storage on all Fuel models — both carbon and alloy. Plus, top tube accessory mounts let you load up even more.


Fresh frame design

    Fuel's new frame gives you tons of room for long dropper posts, bigger shocks, frame bags, and more.


Active Braking Pivot

    Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.

SKU Trek_56291
Frame OCLV Mountain Carbon, removable battery, angle-adjust headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker links, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable trav
Frame el 145mm-160mm
Frame Material Carbon
Headset FSA Orbit, sealed cartridge bearing, 1-1/8' top, 1.5' bottom, 1.5 crown
Weight as Spec'd M - 19.73 kg / 43.5 lbs (with TLR sealant, no tubes)
Weight Limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
Motor TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
Battery TQ 580Wh
E-Bike - Primary Battery Type 360WH
Brake - Brand SRAM
Brake Type Hydraulic disc
Brake SRAM DB 8 4-piston hydraulic disc // SRAM DB 8 4-piston hydraulic disc
Brake Rotor SRAM Centerline 2.0, 6-bolt, 200mm
Brake Rotor Size Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer
Handlebar Race Face Turbine, alloy, 35mm, 40mm rise, 780mm width
Stem Bontrager Elite, 35mm, 0 degree, 45mm length
Grips Trek Line Elite, lock-on
Saddle Bontrager Verse P3, chromoly rails
Seatpost Bontrager Line Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 5150mm length
Drivetrain - Brand SRAM
Rear Derailleur SRAM Eagle 70, T-Type
Crank SRAM EAGLE 70, 160mm length
Shifter SRAM Eagle 70, 12 speed
Chainring SRAM T-Type, 32T, alloy
Cassette SRAM Eagle XS-1270, T-Type,10-52, 12 speed
Chain SRAM Eagle 70, T-Type, 12 speed
Fork - Brand Fox
Fork Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt X axle, 150mm travel
Shock - Brand Fox
Shock Fox Performance Float X, 2-position damper, 205mm x 60mm
Wheel Size 29"
Tires Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50"
Tire Size 29x2.50"
Hub - Front Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub - Rear Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano freehub, Boost148, 12mm thru axle
Skewer - Rear Bontrager Switch thru axle, removable lever
Rims Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve
Rim Strip Bontrager TLR
Small Parts Bontrager TLR sealant, 180 ml/6 oz
_shipping-groups ACYP-ECY
BS Product Type Trail - Light Assist
Discipline Mountain
Model Year 2026
DG code Yes
