Wahoo 24 Trail is a light and tough kids' bike that's ready to roll off-road. Its sturdy aluminum frame is easy to maneuver as they weave their way down the trail, but rugged enough to handle the tough stuff. A 9-speed 1x drivetrain gives them plenty of gears for pedaling up steep trails, and disc brakes provide next-level stopping power to slow their roll or help them stop on a dime on the way back down. Perfect for riders between 51-59" tall.
| SKU | Trek_56351 |
|---|---|
| Frame | Alpha Silver Aluminum, 24" |
| Frame Material | Aluminum |
| Headset | Integrated, sealed cartridge bearings |
| Bottom Bracket | Sealed cartridge, 68mm |
| Weight as Spec'd | 10.50 kg / 23.15 lbs |
| Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 175 pounds (80 kg). |
| Brake - Brand | Tektro |
| Brake Type | Hydraulic disc |
| Brake | Tektro HD-J285 hydraulic disc // Tektro HD-J285 hydraulic disc |
| Brake Rotor | Tektro, 6-bolt, 160mm |
| Brake Rotor Size | Max brake rotor sizes: 160mm front & rear |
| Handlebar | Bontrager alloy, 31.8mm clamp, 20mm rise, 600mm width |
| Stem | Bontrager alloy, 31.8mm clamp, 6 degree, 45mm length |
| Grips | Kids' grip, 110mm width |
| Pedals | VP-225 nylon platform |
| Saddle | Kids' padded, integrated seatpost, Blendr light mount, 31.6x270mm |
| Seat Collar | Bolt-on, 36.4mm |
| Drivetrain - Brand | Microshift |
| Rear Derailleur | microSHIFT Advent RD-M6195M, 40-46T max cog |
| Crank | Alloy, 30T steel chain ring w/ guard. 127mm length |
| Shifter | microSHIFT Advent Quick Trigger Pro SL-M6295, 9 speed |
| Cassette | microSHIFT Advent H093, 11-42, 9 speed |
| Chain | KMC X9 |
| Fork - Brand | Trek |
| Fork | Wahoo 24" carbon, post mount disc brake, ThruSkew 5mm QR |
| Wheel Size | 24" |
| Tire Size - Max | 24x2.40" with or without fenders |
| Wheel - Front | / |
| Tires | Kenda Amrak, 30 tpi, 24x2.20'' |
| Hub - Front | Formula DC-20, alloy, 6-bolt, 100 mm |
| Hub - Rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm |
| Skewer - Front | 135x5mm bolt-on |
| Skewer - Rear | 169x5mm bolt-on |
| Fenders | Trek custom |
| _shipping-groups | SHIPFGK |
| Model Year | 2026 |
| BS Product Type | Trail Hardtails |
