All-New Specialized Levo R

24th Feb 2026

All-New Specialized Levo R

SuperNatural power, agility, and range in a lighter, faster, and more instinctive package. The new Specialized Levo R checks a lot of boxes for a full power e-bike. It's a lightweight package with a full power motor. With 29" wheels, 140mm front travel, and 130mm rear travel, the Levo R is built with a low efficient stance for balance, control, and climbing speed. Rally-tuned geometry with adjustability to really fine-tune the details. Levo R is ready to rally.

Wheel size: 29"
Front travel: 140mm
Rear travel: 130mm
Motor: Full power Turbo 3.1 motor, 850 watts, 111 Nm
Battery: 840 Wh or 600 Wh or run just the 280 Wh range extender for a lighter setup
Range: Up to 4.75 hours of riding
Adjustable geo: BB and chainstay FlipChip, 3 positions on the headtube

Adjustable Geometry:

BB FlipChip
The BB FlipChip has a low position for added stability or a high position for increased pedal clearance.

3 Position Headtube
Steeper for sharper steering or more relaxed for greater stability at speed.

Chainstay FlipChip
Adjust the rear center length for a longer and more stable set up. Run it shorter for a more maneuverable feel.

Geometry Chart:

	S1	S2	S3	S4	S5	S6
Stack	603	607	617	630	644	657
Reach	400	420	450	475	500	525
Head-tube length	96	100	110	125	140	155
Head-tube angle	64.8	65	65	65	65	65
BB height - low	339	339	339	339	339	339
BB drop	36.2	36	36	36	36	36
Trail	127	127	127	127	127	127
Fork length	550	550	550	550	550	550
Fork rake	44	44	44	44	44	44
Front center	716	736	770	801	833	864
Chainstay length	447	447	447	447	447	447
Wheelbase	1161	1181	1215	1246	1277	1309
Top-tube length	540	560	592	620	649	677
Standover	759	765	771	771	778	778
Seat-tube length	374.92	385	405	425	445	465
Seat-tube angle	76.91	77	77	77	77	77
Max seatpost insertion	210	227	249	271	292	312
Min seatpost insertion	80	80	80	80	80	80
