Fuel+ EX 5 is a quiet and capable electric mountain bike that's up for any trail, any time. Its Alpha NEXT Platinum aluminum frame delivers a smooth boost from a compact TQ HPR-60 motor, while a RockShox fork and X-Fusion shock (145mm rear, 150mm front) provide trail-smoothing confidence. A Shimano Deore drivetrain gives you plenty of gears for steep climbs, and 4-piston Shimano M4100 hydraulic brakes provide reliable stopping power.
| SKU | TREK | Fuel + EX 5 |
|---|---|
| Size | Large |
| Frame | Alpha NEXT Platinum aluminum, removable battery, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel |
| Frame | 145mm-160mm |
| Headset | FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown |
| Weight as Spec'd | M - 21.92 kg / 48.33 lbs (with TLR sealant, no tubes) |
| Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
| Motor | TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power |
| Battery | TQ 580Wh |
| Controller | TQ LED display with Bluetooth & ANT+ connectivity |
| Brakeset | Shimano 4-piston hydraulic disc, MT4100 lever, MT420 caliper |
| Brake Rotor | Shimano RT64, centerlock, 203mm |
| Handlebar | Bontrager Comp, alloy, 31.8mm, 40mm rise, 780mm width |
| Stem | Bontrager Comp, 31.8mm, 7 degree, 35mm length |
| Grips | Trek Line Comp, nylon lock-on |
| Saddle | Bontrager Verse Short, stainless steel rails |
| Rear Derailleur | Shimano Deore M6100, long cage |
| Crank Arm | E*thirteen E*spec Plus, 160mm length |
| Shifter | Shimano Deore M6100, 12 speed |
| Chainring | E*Thirteen Helix Core Steel 32t steel, 55mm chainline |
| Cassette | Shimano Deore M6100, 10-51, 12 speed |
| Chain | Shimano Deore M6100, 12 speed |
| Fork | Rockshox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 offset, Boost110, 15mm Maxle Stealth, 150mm travel |
| Shock | X-Fusion Pro 2, 2-position damper, 205mm x 60mm |
| Wheel Size | 29" |
| Hub - Front | Shimano TC500 alloy, centerlock, 110x15mm thru axle |
| Hub - Rear | Shimano TC500 alloy, centerlock, 148x12mm thru axle |
| Rims | Front: Size: S, XL, L, M Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve | rear: Size: S, XL, L, M Bontrager Line TLR 30, Tubeless Ready, 32-hole, Presta valve |
| _shipping-groups | Restricted |
| Discipline | Mountain |
| BS Product Type | Trail Light Assist |
