Save 24%

Rocky Mountain

2025 | Instinct Powerplay SL Carbon 90

$11,249.95

$11,249.95 ~~$14,999.00~~

Shipping calculated at checkout.

Color: White/Carbon/Grey

Size: X-Large

X-Small Small Medium Large X-Large

SKU:B0410XL2

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette Sram X0 Eagle Transmission 10-52T

Chain Sram X0 Transmission

Crankset Race Face ERA Cinch | 34T T-Type Ring | 30mm Spindle | XS - XL = 165mm

Rear derailleur Sram X0 Eagle Transmission Wireless

Shifter Sram AXS Pod Ultimate Controller

Brakes

Brakeset Sram Code Ultimate Stealth 4 Piston | Metal Pads

Brake rotor Sram HS2 200mm | Sram HS2 200mm

Cockpit

Grips tape ODI Elite Pro Lock On

Saddle WTB Volt Fusion Form 142 | Titanium Rails

Seatpost Fox Transfer Factory Series 30.9mm | XS = 120mm | SM = 150mm | MD = 180mm | LG - XL = 210mm

Stem Race Face Turbine R | 0° Rise | All Sizes = 40mm

Wheels

Tires Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | Tubeless Set Up | Sealant Incl

Wheels Race Face ERA Carbon | Tuned Front-Specific Rim and Hub Design | Race Face ERA Carbon | Tuned Rear-Specific Rim and Hub Design

Wheel size 29"

Suspension

Fork Fox 36 Float EVOL GRIP X2 Factory Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset

Frame

Bottom bracket Race Face BB92 30mm

Frame material Carbon

Platform wheel size 29"

Seatpost Fox Transfer Factory Series 30.9mm | XS = 120mm | SM = 150mm | MD = 180mm | LG - XL = 210mm

E-Bike System

Battery 480 Wh Removable Integrated Li-Ion

Description

The Instinct Powerplay SL Carbon packs a punch in a lightweight package. Powered by the all-new Dyname S4 Lite drive system, this bike rides like a trail bike with the power to explore further than ever before. With adjustable geometry, refined suspension kinematics, and MX compatibility, the Carbon Instinct Powerplay SL delivers unreal levels of playfulness and agility, lap after lap… after lap.

Geometry Chart

Shock Position

Wheel Size

Measurement	X-Small Position 1 · 27.5"	X-Small Position 2 · 27.5"	X-Small Position 3 · 27.5"	X-Small Position 4 · 27.5"	Small Position 1 · 29/27.5" MX	Small Position 2 · 29/27.5" MX	Small Position 3 · 29/27.5" MX	Small Position 4 · 29/27.5" MX	Medium Position 1 · 29/27.5" MX	Medium Position 2 · 29/27.5" MX	Medium Position 3 · 29/27.5" MX	Medium Position 4 · 29/27.5" MX	Large Position 1 · 29/27.5" MX	Large Position 2 · 29/27.5" MX	Large Position 3 · 29/27.5" MX	Large Position 4 · 29/27.5" MX	X-Large Position 1 · 29/27.5" MX	X-Large Position 3 · 29/27.5" MX	X-Large Position 2 · 29/27.5" MX	X-Large Position 4 · 29/27.5" MX	Small Position 1 · 29"	Small Position 2 · 29"	Small Position 3 · 29"	Small Position 4 · 29"	Medium Position 1 · 29"	Medium Position 2 · 29"	Medium Position 3 · 29"	Medium Position 4 · 29"	Large Position 1 · 29"	Large Position 2 · 29"	Large Position 3 · 29"	Large Position 4 · 29"	X-Large Position 1 · 29"	X-Large Position 2 · 29"	X-Large Position 3 · 29"	X-Large Position 4 · 29"
Reach (mm)	399	401	405	407	425	427	430	433	450	452	455	458	475	477	480	482	505	510	507	512	425	427	430	432	450	452	455	457	475	477	480	482	505	507	510	512
Stack (mm)	590	589	586	585	618	616	614	612	622	621	618	617	636	634	632	630	645	641	643	639	618	616	614	612	622	621	618	617	636	634	632	630	645	643	641	639
Head Tube Angle (°)	63.5°	63.7°	64°	64.2°	63.5°	63.7°	64°	64.2°	63.5°	63.7°	64°	64.2°	63.5°	63.7°	64°	64.2°	63.5°	64°	63.7°	64.2°	63.5°	63.7°	64°	64.2°	63.5°	63.7°	64°	64.2°	63.5°	63.7°	64°	64.2°	63.5°	63.7°	64°	64.2°
Seat Tube Angle (°)	76.4°	76.6°	77°	77.2°	76.8°	77.2°	77.5°	77.7°	76.5°	76.7°	77°	77.2°	76.5°	76.6°	77°	77.2°	76.5°	77°	76.7°	77.2°	77°	77.2°	77.5°	77.7°	76.5°	76.7°	77°	77.2°	76.5°	76.7°	77°	77.2°	76.5°	76.7°	77°	77.2°
Wheelbase (mm)	1157	1156	1154	1153	1202	1201	1199	1198	1229	1228	1226	1225	1270	1269	1268	1267	1305	1309	1304	1301	1205	1204	1203	1202	1232	1231	1230	1229	1274	1273	1272	1271	1308	1307	1306	1305
Head Tube Length (mm)	105	105	105	105	105	105	105	105	110	110	110	110	125	125	125	125	135	135	135	135	105	105	105	105	110	110	110	110	125	125	125	125	135	135	135	135
Seat Tube Length (mm)	355	355	355	355	365	365	365	365	410	410	410	410	440	440	440	440	470	470	470	470	365	365	365	365	410	410	410	410	440	440	440	440	470	470	470	470
BB Drop (mm)	24	22	17	14	24	21	17	14	24	21	17	14	24	21	17	14	24	17	21	14	39	36	32	29	39	36	32	29	39	36	32	29	39	36	32	29
Standover Height (mm)	775	777	780	782	785	787	790	792	809	811	814	816	807	810	813	815	807	813	810	815	785	787	790	792	809	811	813	816	808	810	813	815	807	810	813	815

Part Numbers

Size	White/Carbon/Grey
X-Small	SKUB0410XS2 UPC770416001020
Small	SKUB0410SM2 UPC770416000986
Medium	SKUROC46598551Y VPNRMB_B0410MD2 UPC770416000962 MPNB0410MD2
Large	SKUROC46748116Y VPNRMB_B0410LG2 UPC770416000948 MPNB0410LG2
X-Large	SKUROC46494080Y VPNRMB_B0410XL2 UPC770416001006 MPNB0410XL2

Size Chart

Rocky Mountain Instinct PP Sizing

Size	Rider height (in)	Rider height (cm)
X-Small	4’7” - 5'2”	147.5 - 157.5 cm
Small	5’0” - 5’6”	152.5 - 167 cm
Medium	5’4” - 5’10”	162.5 - 177.5 cm
Large	5’8” - 6’2”	172.5 - 188 cm
X-Large	6’0” - 6’6”	183 - 198 cm
