Trek

2026 | Checkpoint SL 6 AXS Gen 3

$5,199.99

Shipping calculated at checkout.

Color: Era White/Buff Beige

Size: X-Small

X-Small Small Medium Medium/Large Large X-Large

SKU:TRE47238123E

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette Sram Rival XPLR XG-1351, 10-46, 13 speed

Chain SRAM Rival E1, 12/13 speed

Rear derailleur SRAM Rival XPLR AXS, 46T max cog

Shifter SRAM Rival AXS, 13 speed

Brakes

Brake rotor SRAM Paceline, rounded, centerlock, 160mm

Brake type Hydraulic disc

Rotor size Max brake rotor sizes: 180mm front & rear

Cockpit

Handlebars Bontrager Elite Gravel, alloy, 40cm width

Saddle Verse Short Comp, steel rails, 145mm width

Seatpost Bontrager carbon, 27.2mm, 8mm offset, 330mm length

Stem Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 70mm length

Wheels

Rims Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width

Tires Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42mm

Valves Bontrager TLR sealant, 180 ml/6 oz

Wheel size 700c

Suspension

Fork Trek Checkpoint, full carbon, tapered steerer, rack mounts, fender mounts, flat mount disc, 12x100mm thru axle

Fork brand Trek

Fork travel 40 mm (XS: compatible with rigid fork only)
See Checkpoint SL Gen 3 FAQ for compatible options

Frame

Bottom bracket SRAM DUB Wide, T47 threaded, internal bearing

Frame 500 Series OCLV Carbon, IsoSpeed, downtube storage door, hidden fender mounts, rack mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat mount disc, integrated chainkeeper, removable FD hanger, UDH, 142x12mm chamfered thru axle

Frame material Carbon

Platform wheel size 700C

Seatpost Bontrager carbon, 27.2mm, 8mm offset, 330mm length

Seatpost standard 27.2mm

Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

E-Bike System

Battery SRAM eTap battery pack (with charger)

Battery type Li-Ion 300mAh 7.4 Volt

Description

Checkpoint SL 6 AXS Gen 3 is a carbon gravel bike ready for far-out adventures. Its lightweight carbon frame is designed with comfort-focused Gravel Endurance geometry, clearance for beefy 50mm tires (as measured), and plenty of frame and fork mounts. Plus, IsoSpeed frame technology helps soak up jarring road vibrations, so you can you float over chatter and potholes. It's ready to cut loose with a SRAM Rival AXS E1 wireless 13-speed groupset.

Geometry Chart

Measurement	Small	Medium	Medium / Large	X-Small
Reach (mm)	386	391	397	380
Stack (mm)	556	579	601	535
Head Tube Angle (°)	71.4°	71.6°	72.0°	71.0°
Seat Tube Angle (°)	74.0°	73.3°	73.3°	74.0°
Wheelbase (mm)	1022	1034	1042	1013
Chainstay Length (mm)	430	430	430	430
Head Tube Length (mm)	106	130	151	86
Seat Tube Length (mm)	480	505	530	445
BB Drop (mm)	76	76	76	76
Rake (mm)	49	49	49	49
Trail (mm)	7	7	6	7
Axle to Crown (mm)	556	579	601	535

Part Numbers

Size	Era White/Buff Beige	Dark Green/Ivy Smoke Splatter
X-Small	SKUTRE47238123E VPNTrek_5334725 UPC197216228226 MPN5334725	SKUTRE55737117R VPNTrek_5334719 UPC197216228165 MPN5334719
Small	SKUCHE385766353 VPNTrek_5334726 UPC197216228233 MPN5334726	SKUTRE54834176R VPNTrek_5334720 UPC197216228172 MPN5334720
Medium	SKUCHE384829153 VPNTrek_5334727 UPC197216228240 MPN5334727	SKUCHE464503323 VPNTrek_5334721 UPC197216228189 MPN5334721
Medium/Large	SKUTRE47904722E VPNTrek_5334728 UPC197216228257 MPN5334728	SKUCHE47564743 VPNTrek_5334722 UPC197216228196 MPN5334722
Large	SKUTRE46118595E VPNTrek_5334729 UPC197216228264 MPN5334729	SKUCHE468838973 VPNTrek_5334723 UPC197216228202 MPN5334723
X-Large	SKUTRE47444324E VPNTrek_5334730 UPC197216228271 MPN5334730	SKUTRE55774676R VPNTrek_5334724 UPC197216228219 MPN5334724

Size Chart

Trek | Gravel

Size	Size (cm)	Rider height (in)	Rider height (cm)	Inseam (in)	Inseam (cm)
X-Small	N/A	4'8" - 5'2"	143 - 158 cm	26" - 29"	67 - 74 cm
Small	49cm	5'2" - 5'5"	158 - 164 cm	29" - 30"	74 - 77 cm
Medium	52-54cm	5'5" - 5'10"	164 - 177 cm	30" - 33"	77 - 83 cm
Medium/Large	56cm	5'10" - 6'2"	177 - 188 cm	33" - 35"	83 - 88 cm
Large	58cm	6'2" - 6'4"	188 - 194 cm	35" - 36"	88 - 91 cm
X-Large	61cm	6'4" - 6'8"	194 - 203 cm	36" - 37"	91 - 95 cm
