Sold out

Trek

2026 | Fuel+ EX 9.8 XT Gen 2

$12,499.99

Shipping calculated at checkout.

Color: Lichen Green/Keswick Green Splatter

Size: Small

Small Medium Large X-Large XX-Large

SKU:FUE485147172

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette Shimano XT M8200, 10-51, 12 speed

Chain Shimano Ultegra/XT M8100, 12 speed

Chainring E*Thirteen Helix Core Steel 32t steel, 55mm chainline

Crank length E*thirteen E*spec Plus, 160mm length

Rear derailleur Shimano XT M8100, long cage

Shifter Shimano XT M8100, 12 speed

Brakes

Brake rotor Shimano RT86, 6-bolt, 203mm

Brake type Hydraulic disc

Caliper Shimano XT M8200 4-piston hydraulic disc // Shimano XT M8200 4-piston hydraulic disc

Rotor size Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer

Cockpit

Grips tape Trek Line Elite, lock-on

Handlebars Race Face ERA, carbon, 35mm, 27.5mm rise, 800mm width

Saddle Verse Short Comp, steel rails, 145mm width

Seatpost Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length

Stem Bontrager Elite, 35mm, 0 degree, 45mm length

Wheels

Tires Maxxis Minion DHF, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5' // Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5'

Valves Bontrager TLR sealant, 180 ml/6 oz

Wheel size 29"

Suspension

Fork Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 150mm travel

Fork brand Fox

Shock Fox Factory Float X, 205mm x 60mm

Shock brand Fox

Frame

Frame OCLV Mountain Carbon, removable battery, angle-adjust headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker links, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel 145mm-160mm

Frame material Carbon

Seatpost Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length

Weight as spec d M - 20.10 kg / 44.32 lbs (with TLR sealant, no tubes)

Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

E-Bike System

Battery TQ 580Wh

Battery type 360WH

Motor TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power

Motor controller TQ color LED display with Bluetooth & ANT+ connectivity

Description

Flow, tech, or steeps — Fuel is up to get down. This trail ripper features ultra-adjustable geometry that lets you choose your own adventure, whether you’re after a stoic trail tamer, rowdy MX ride, or enduro-ready beast. Three build options and endless tweaks mean you can get a ride that’s fine-tuned for your style and stomping grounds. Wherever the trail leads you, Fuel is ready to send. Fuel+ EX 9.8 XT is an adaptable carbon e-MTB ready for sky-high climbs and dreamy descents. Its OCLV Mountain Carbon frame delivers a smooth boost from TQ's HPR-60 motor, while a Fox Factory suspension package (145mm rear, 150mm front) gives you buttery-smooth control through the rough. A mechanical Shimano XT 12-speed drivetrain gives you clean, reliable shifting and 4-piston XT M8200 brakes provide excellent modulation and stop-on-a-dime power.

Geometry Chart

Measurement	Small	Medium	Large	X-Large	XX-Large
Reach (mm)	431	460	485	510	530
Stack (mm)	624	624	638	651	665
Head Tube Angle (°)	64.6°	64.5°	64.5°	64.5°	64.5°
Seat Tube Angle (°)	72.7°	72.6°	72.6°	72.6°	72.6°
Wheelbase (mm)	1200	1232	1258	1298	1330
Chainstay Length (mm)	441	444	444	447	452
Head Tube Length (mm)	110	110	125	140	155
Seat Tube Length (mm)	370	400	420	455	475
BB Drop (mm)	34	35	35	35	35
BB Height (mm)	339	339	339	339	339
Rake (mm)	44	44	44	44	44
Trail (mm)	13	13	13	13	13
Axle to Crown (mm)	624	624	638	651	665

Part Numbers

Size	Lichen Green/Keswick Green Splatter	Carbon Smoke/Lithium Grey Marble	Gloss Navy Smoke/Matte Trek Black
Small	SKUFUE485147172 VPNTrek_5340888 UPC197216279372 MPN5340888	SKUFUE452205942 VPNTrek_5340883 UPC197216279327 MPN5340883	SKUFUE45523842 VPNTrek_5340893 UPC197216279426 MPN5340893
Medium	SKUFUE481284462 VPNTrek_5340889 UPC197216279389 MPN5340889	SKUFUE45541232 VPNTrek_5340884 UPC197216279334 MPN5340884	SKUFUE458344812 VPNTrek_5340894 UPC197216279433 MPN5340894
Large	SKUFUE481455092 VPNTrek_5340890 UPC197216279396 MPN5340890	SKUFUE453199482 VPNTrek_5340885 UPC197216279341 MPN5340885	SKUFUE453694812 VPNTrek_5340895 UPC197216279440 MPN5340895
X-Large	SKUFUE495265932 VPNTrek_5340891 UPC197216279402 MPN5340891	SKUFUE462134632 VPNTrek_5340886 UPC197216279358 MPN5340886	SKUFUE462470992 VPNTrek_5340896 UPC197216279457 MPN5340896
XX-Large	SKUFUE504049002 VPNTrek_5340892 UPC197216279419 MPN5340892	SKUFUE471099472 VPNTrek_5340887 UPC197216279365 MPN5340887	SKUFUE472883162 VPNTrek_5340897 UPC197216279464 MPN5340897

Size Chart

Trek | Mountain

Size	Rider height (in)	Rider height (cm)	Inseam (in)	Inseam (cm)
X-Small	4'9" - 5'1"	145 - 155 cm	27" - 29"	69 - 73 cm
Small	5'1" - 5'5"	155 - 165 cm	29" - 31"	74 - 78 cm
Medium	5'5" - 5'10"	165 - 177 cm	31" - 33"	79 - 83 cm
Medium/Large	5'8" - 5'11"	173 - 180 cm	32" - 34"	81 - 86 cm
Large	5'10" - 6'2"	177 - 188 cm	33" - 35"	84 - 89 cm
X-Large	6'2" - 6'5"	188 - 195 cm	35" - 36"	89 - 91 cm
XX-Large	6'5" - 6'8"	195 - 203 cm	36" - 38"	91 - 97 cm

Adapt, rip, repeat

Only you can define your perfect trail bike — that's why Fuel is available in three adjustability-packed configurations. Get do-it-all capability with EX, go pop-happy with MX, or charge through it all with LX.

Adjustable leverage rate

Want more bottom-out resistance without giving up small-bump sensitivity? Flip the chip in the lower shock mount for a more progressive leverage rate.

Zero stack integrated headset

With a ZS standard headset, you've got tons of options for aftermarket upgrades, including angle adjust or anodized colors.

Storage and accessory mounts

Stash ride essentials with in-frame storage on all Fuel models — both carbon and alloy. Plus, top tube accessory mounts let you load up even more.

2026 | Fuel+ EX 9.8 XT Gen 2
