Sold out

Trek

2026 | Fuel+ MX 9.8 XT Gen 2

$12,499.99

Shipping calculated at checkout.

Color: Gloss Navy Smoke/Matte Trek Black

Size: Small

Small Medium Large X-Large XX-Large

SKU:TRE50317147L

Why Buy a Bike From The Bike Shop?

15% off Parts & Accessories
When you buy a bike at The Bike Shop, you get 15% off of parts and accessories for the first 30 days following your bike purchase. The discount will automatically apply in the checkout at the time of purchase with your bike. This excludes items already marked down and some brands.

Service Plan
If you're local to Calgary or Canmore, you also get one complimentary complete tune-up within the first 16 months of owning the bike. Also included is a lifetime of unlimited service checks to keep you informed on the overall condition of your bike.

After Purchase Support
You're not on your own after you buy a bike from us. We have a dedicated e-comm team that is here to assist if you need help with anything. We also created video tutorials on how to unbox your bike when it arrives and get it ready to read.

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Cargo bikes:
Due to the size of the box that cargo bikes ship in, we are unable to ship cargo bikes directly to your address. Cargo bikes are shipped to a Manitoulin Depot for you to pick-up. For more detail, visit our shipping page.

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette Shimano XT M8200, 10-51, 12 speed

Chain Shimano Ultegra/XT M8100, 12 speed

Chainring E*Thirteen Helix Core Steel 32t steel, 55mm chainline

Crank length E*thirteen E*spec Plus, 160mm length

Rear derailleur Shimano XT M8100, long cage

Shifter Shimano XT M8100, 12 speed

Brakes

Brake rotor Shimano RT86, 6-bolt, 203mm

Brake type Hydraulic disc

Caliper Shimano XT M8200 4-piston hydraulic disc // Shimano XT M8200 4-piston hydraulic disc

Rotor size Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer

Cockpit

Grips tape Trek Line Elite, lock-on

Handlebars Race Face ERA, carbon, 35mm, 27.5mm rise, 800mm width

Saddle Verse Short Comp, steel rails, 145mm width

Seatpost Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length

Stem Bontrager Elite, 35mm, 0 degree, 45mm length

Wheels

Tires Maxxis Assegai, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5' // Maxxis Minion DHR II, tubeless ready, 3C, Double Down, MAXXGRIP, 27.5x2.5"

Valves Bontrager TLR sealant, 180 ml/6 oz

Wheel size 29"/27.5" MX

Suspension

Fork Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 160mm travel

Fork brand Fox

Shock Fox Factory Float X, 205mm x 60mm

Shock brand Fox

Frame

Frame OCLV Mountain Carbon, removable battery, angle-adjust headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker links, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel 145mm-160mm

Frame material Carbon

Platform wheel size 29"/27.5" MX

Seatpost Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length

Weight as spec d M - 19.72 kg / 43.48 lbs (with TLR sealant, no tubes)

Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

E-Bike System

Battery TQ 580Wh

Battery type 360WH

Motor TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power

Motor controller TQ color LED display with Bluetooth & ANT+ connectivity

Description

Fuel+ MX 9.8 XT is a chaos-craving carbon e-MTB for chasing side hits, lap after lap. It starts off with an OCLV Mountain Carbon frame with TQ's HPR60 motor, speced with a Fox Factory suspension package (150mm rear, 160mm front), and MX wheels for getting wild on the trail. A mechanical Shimano XT 12-speed drivetrain gives you clean, reliable shifting and 4-piston XT M8200 brakes provide excellent modulation and stop-on-a-dime power.

Geometry Chart

Measurement	X-Large
Reach (mm)	507
Stack (mm)	654
Head Tube Angle (°)	64.2°
Seat Tube Angle (°)	72.3°
Wheelbase (mm)	1301
Chainstay Length (mm)	444
Head Tube Length (mm)	140
Seat Tube Length (mm)	455
BB Drop (mm)	31
BB Height (mm)	343
Rake (mm)	44
Trail (mm)	13
Axle to Crown (mm)	654

Part Numbers

Size	Gloss Navy Smoke/Matte Trek Black	Carbon Smoke/Lithium Grey Marble	Lichen Green/Keswick Green Splatter
Small	SKUTRE50317147L VPNTrek_5340938 UPC197216280323 MPN5340938	SKUTRE51659765B VPNTrek_5340928 UPC197216280224 MPN5340928	SKUTRE51845428L VPNTrek_5340933 UPC197216280279 MPN5340933
Medium	SKUTRE50892112L VPNTrek_5340939 UPC197216280330 MPN5340939	SKUTRE5197488B VPNTrek_5340929 UPC197216280231 MPN5340929	SKUTRE51250581L VPNTrek_5340934 UPC197216280286 MPN5340934
Large	SKUTRE50317946L VPNTrek_5340940 UPC197216280347 MPN5340940	SKUTRE51941381B VPNTrek_5340930 UPC197216280248 MPN5340930	SKUTRE51950445L VPNTrek_5340935 UPC197216280293 MPN5340935
X-Large	SKUFUE467039062 VPNTrek_5340941 UPC197216280354 MPN5340941	SKUTRE52757326B VPNTrek_5340931 UPC197216280255 MPN5340931	SKUTRE52498081L VPNTrek_5340936 UPC197216280309 MPN5340936
XX-Large	SKUTRE52793849L VPNTrek_5340942 UPC197216280361 MPN5340942	SKUTRE53967160B VPNTrek_5340932 UPC197216280262 MPN5340932	SKUTRE53261043L VPNTrek_5340937 UPC197216280316 MPN5340937

Size Chart

Trek | Mountain

Size	Rider height (in)	Rider height (cm)	Inseam (in)	Inseam (cm)
X-Small	4'9" - 5'1"	145 - 155 cm	27" - 29"	69 - 73 cm
Small	5'1" - 5'5"	155 - 165 cm	29" - 31"	74 - 78 cm
Medium	5'5" - 5'10"	165 - 177 cm	31" - 33"	79 - 83 cm
Medium/Large	5'8" - 5'11"	173 - 180 cm	32" - 34"	81 - 86 cm
Large	5'10" - 6'2"	177 - 188 cm	33" - 35"	84 - 89 cm
X-Large	6'2" - 6'5"	188 - 195 cm	35" - 36"	89 - 91 cm
XX-Large	6'5" - 6'8"	195 - 203 cm	36" - 38"	91 - 97 cm
