Trek

2027 | FX 2 Stepover Gen 4

$979.99

Shipping calculated at checkout.

Color: Carbon Dark Grey

Size: Small

X-Small Small Medium Large X-Large

SKU:FX220227953Y

Why Buy a Bike From The Bike Shop?

15% off Parts & Accessories
When you buy a bike at The Bike Shop, you get 15% off of parts and accessories for the first 30 days following your bike purchase. The discount will automatically apply in the checkout at the time of purchase with your bike. This excludes items already marked down and some brands.

Service Plan
If you're local to Calgary or Canmore, you also get one complimentary complete tune-up within the first 16 months of owning the bike. Also included is a lifetime of unlimited service checks to keep you informed on the overall condition of your bike.

After Purchase Support
You're not on your own after you buy a bike from us. We have a dedicated e-comm team that is here to assist if you need help with anything. We also created video tutorials on how to unbox your bike when it arrives and get it ready to read.

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Cargo bikes:
Due to the size of the box that cargo bikes ship in, we are unable to ship cargo bikes directly to your address. Cargo bikes are shipped to a Manitoulin Depot for you to pick-up. For more detail, visit our shipping page.

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette Shimano LINKGLIDE LG300, 11-46, 9 speed

Chain Shimano LG500

Rear derailleur Shimano CUES U4000

Shifter Shimano U4000, 9 speed

Brakes

Brake rotor Tektro wave, 6-bolt, 160mm

Brake type Hydraulic disc

Cockpit

Grips tape Trek Line Ergonomic Comp, lock-on

Handlebars Bontrager alloy, 31.8mm, 15mm rise, 600mm width

Pedals Bontrager City pedals

Saddle Bontrager Sport

Seatpost Bontrager alloy, 27.2mm, 12mm offset, 330mm length

Stem Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 90mm length

Wheels

Front hub Formula DC-20, alloy, 6-bolt, 5x100 mm QR

Rear hub Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR

Rims Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve

Tires Bontrager H2 Comp, wire bead, 30 tpi, 700x35mm

Wheel size 700c

Suspension

Fork FX alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR

Fork brand Trek

Frame

Bottom bracket Sealed cartridge, 68mm

Frame Alpha Gold Aluminum, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR

Frame material Aluminum

Seatpost Bontrager alloy, 27.2mm, 12mm offset, 330mm length

Weight as spec d M - 12.10 kg / 26.68 lbs

Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

Description

FX 2 is a stylish and versatile hybrid bike for riding all around town. Exercise, commute, or ride for fun with the wide range of speeds, reliable disc brakes that let you stop on a dime, and loads of mounts for accessories.

Geometry Chart

Measurement	Small	Medium	Large	X-Large	X-Small
Reach (mm)	385	393	399	409	383
Stack (mm)	568	594	620	648	543
Head Tube Angle (°)	70.5°	71.0°	71.5°	72.5°	70.0°
Seat Tube Angle (°)	74.5°	74.0°	73.5°	72.5°	75.0°
Wheelbase (mm)	1059	1070	1080	1087	1052
Chainstay Length (mm)	447	447	447	447	447
Head Tube Length (mm)	140	165	190	215	115
Seat Tube Length (mm)	375	420	465	520	330
BB Drop (mm)	65	65	65	65	65
BB Height (mm)	285	285	285	285	285
Rake (mm)	50	50	50	50	50
Trail (mm)	7	7	6	6	7
Axle to Crown (mm)	568	594	620	648	543

Part Numbers

Size	Carbon Dark Grey	Fjord Blue	Fury Red
X-Small	SKUFX221224547Y VPNTrek_5336668 UPC197216243397 MPN5336668	SKUTRE28394835E VPNTrek_5336678 UPC197216243496 MPN5336678	SKUFX214390550D VPNTrek_5336673 UPC197216243441 MPN5336673
Small	SKUFX220227953Y VPNTrek_5336669 UPC197216243403 MPN5336669	SKUTRE2747744E VPNTrek_5336679 UPC197216243502 MPN5336679	SKUFX213924001D VPNTrek_5336674 UPC197216243458 MPN5336674
Medium	SKUFX220534089Y VPNTrek_5336670 UPC197216243410 MPN5336670	SKUTRE27204033E VPNTrek_5336680 UPC197216243519 MPN5336680	SKUFX213970837D VPNTrek_5336675 UPC197216243465 MPN5336675
Large	SKUFX220643166Y VPNTrek_5336671 UPC197216243427 MPN5336671	SKUTRE2733949E VPNTrek_5336681 UPC197216243526 MPN5336681	SKUFX2135839D VPNTrek_5336676 UPC197216243472 MPN5336676
X-Large	SKUFX221613112Y VPNTrek_5336672 UPC197216243434 MPN5336672	SKUTRE28644620E VPNTrek_5336682 UPC197216243533 MPN5336682	SKUFX214536768D VPNTrek_5336677 UPC197216243489 MPN5336677

Size Chart

Trek | City/Hybrid

Size	Rider height (in)	Rider height (cm)	Inseam (in)	Inseam (cm)
X-Small	4'10" - 5'1"	147 - 155 cm	27" - 29"	69 - 73 cm
Small	5'1" - 5'5"	155 - 165 cm	28" - 31"	72 - 78 cm
Medium	5'5" - 5'9"	165 - 175 cm	30" - 33"	77 - 83 cm
Large	5'9" - 6'1"	175 - 186 cm	32" - 35"	82 - 88 cm
X-Large	6'1" - 6'6"	186 - 197 cm	34" - 37"	87 - 93 cm
One Size	4'11" - 6'10"	150 - 208 cm	N/A	N/A
