Cervelo

2027 | S5 Maps LTD - SRAM Red AXS

$18,900.00

Shipping calculated at checkout.

Color: LTD Maps

Size: 56cm

48cm 51cm 54cm 56cm 58cm 61cm

SKU:CER32460339K

Why Buy a Bike From The Bike Shop?

15% off Parts & Accessories
When you buy a bike at The Bike Shop, you get 15% off of parts and accessories for the first 30 days following your bike purchase. The discount will automatically apply in the checkout at the time of purchase with your bike. This excludes items already marked down and some brands.

Service Plan
If you're local to Calgary or Canmore, you also get one complimentary complete tune-up within the first 16 months of owning the bike. Also included is a lifetime of unlimited service checks to keep you informed on the overall condition of your bike.

After Purchase Support
You're not on your own after you buy a bike from us. We have a dedicated e-comm team that is here to assist if you need help with anything. We also created video tutorials on how to unbox your bike when it arrives and get it ready to read.

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Cargo bikes:
Due to the size of the box that cargo bikes ship in, we are unable to ship cargo bikes directly to your address. Cargo bikes are shipped to a Manitoulin Depot for you to pick-up. For more detail, visit our shipping page.

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette SRAM Red E1, 10-33T, 12-Speed

Chain SRAM Red E1

Crankset SRAM Red AXS E1, 50/37T, DUB, with power meter

Crank length Size 48 - 160mm Size 51 - 165mm Size 54 - 170mm Size 56 - 170mm Size 58 - 172.5mm Size 61 - 172.5mm

Front derailleur SRAM Red AXS E1

Rear derailleur SRAM Red AXS E1

Shifter SRAM Red AXS E1

Brakes

Brake rotor SRAM Paceline X Centerlock

Cockpit

Handlebars Cervélo HB19 Carbon | Size 48 - 36cm Size 51 - 38cm Size 54 - 40cm Size 56 - 40cm Size 58 - 40cm Size 61 - 40cm

Saddle Fizik Arione R1 Light

Seatpost Cervélo SP34 Carbon | Size 48 - 0mm Size 51 - 0mm Size 54 - 0mm Size 56 - 0mm Size 58 - 0mm Size 61 - 15mm

Stem Cervélo HB19 Carbon | Size 48 - 80mm Size 51 - 90mm Size 54 - 100mm Size 56 - 100mm Size 58 - 110mm Size 61 - 120mm

Wheels

Model Reserve 57TA | 64TA

Tires Vittoria Corsa Pro TLR G2.0 700x29c

Wheels Reserve 57TA, DT Swiss 180, 12x100mm, 24H, centerlock, tubeless compatible | Reserve 64TA, DT Swiss 180, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible

Suspension

Fork Cervélo All-Carbon, Bayonet S5 Fork

Frame

Bottom bracket SRAM DUB Ceramic, BBright

Bottom bracket standard BB Right

Cable routing Internal

Frame material Carbon

Headset FSA SL IS2 1-1/8, 36° x 45° / 1-3/8, 36° x 45°

Platform wheel size 700C

Weight as spec d 7.3 kgs

Description

PURE SPEED
 The S5 is a sport-wide benchmark for speed and aerodynamic efficiency—with the race results to back it up. From Wout van Aert winning the Green Jersey by the biggest margin of victory in modern history, to Simon Yates riding himself into the maglia rosa, S5’s iconic V-stem and bayonet fork are a fixture at the front of the professional peloton. The new S5 builds on that legacy of speed by getting even faster, evolving the front end, and going on a bit of a diet, making it an even more potent partner for the fastest riders in the world.
 The new bike is over 6 Watts faster than its predecessor, 124 grams lighter, and retains the handling, poise, and stability that riders everywhere love. The biggest changes are at the front of the bike, where the most significant aerodynamic performance comes from. The fork legs and head tube got quite a bit deeper, and the all-new, one-piece handlebar/ stem builds on the original V-stem concept—and gets even faster.
 Cervélo and Reserve co-developed the new Reserve 57|64 Turbulent Aero wheels specifically for use in the S5 frame. The offset of the wheels perfectly matches the asymmetry of the S5 seat tube, and they tuck right into the wheel cut outs. This ensures that airflows smoothly over the entire bike, and Reserve’s Turbulent Aero approach makes them incredibly stable, even in crosswinds.

Only 650 total frames produced | one-piece carbon cockpit | carbon seatpost
50/37T | 10-33T | 12-speed | power meter | ceramic BB
Reserve 57|64TA carbon wheelset | DT Swiss 180 hubs

Geometry Chart

Measurement	48cm · 700c	51cm · 700c	54cm · 700c	56cm · 700c	58cm · 700c	61cm · 700c
Reach (mm)	367	376	384	392	401	409
Stack (mm)	496	519	542	565	588	608
Head Tube Angle (°)	71	72	73	73.5	73.5	73.5
Seat Tube Angle (°)	73	73	73	73	73	73
Wheelbase (mm)	973	974	975	982	999	1013
Chainstay Length (mm)	405	405	405	405	405	405
Head Tube Length (mm)	64	82	104	125	152	173
BB Drop (mm)	75	75	72	72	70	70
Rake (mm)	59	53	47	44	44	44
Trail (mm)	56	56	56	56	56	56
Front Center (mm)	579	580	581	588	604	617
Standover Height (mm)	712	734	758	781	804	822

Part Numbers

Size	LTD Maps
48cm	SKU0M0S5GRX4C48 UPC0M0S5GRX4C48 MPN0M0S5GRX4C48
51cm	SKU0M0S5GRX4C51 UPC0M0S5GRX4C51 MPN0M0S5GRX4C51
54cm	SKU0M0S5GRX4C54 MPN0M0S5GRX4C54
56cm	SKUCER32460339K UPC0M0S5GRX4C56 MPN0M0S5GRX4C56
58cm	SKU0M0S5GRX4C58 UPC0M0S5GRX4C58 MPN0M0S5GRX4C58
61cm	SKU0M0S5GRX4C61 UPC0M0S5GRX4C61 MPN0M0S5GRX4C61

Size Chart

Cervelo Road Sizing

Size	Size (cm)	Rider height (in)	Rider height (cm)
—	48	4'11"-5'3"	150-160cm
—	51	5'3"-5'5"	160-168cm
—	54	5'5"-5'9"	168-175cm
—	56	5'9"-6"	175-184cm
—	58	6"-6'4"	184-192cm
—	61	6'4"-6'7"	192-200cm

2027 | S5 Maps LTD - SRAM Red AXS
