Rocky Mountain

2027 | Altitude A30

$4,799.00

Shipping calculated at checkout.

Color: Black/Black

Size: Small

Small Medium Large X-Large

SKU:BALTA3027SMBK

Why Buy a Bike From The Bike Shop?

15% off Parts & Accessories
When you buy a bike at The Bike Shop, you get 15% off of parts and accessories for the first 30 days following your bike purchase. The discount will automatically apply in the checkout at the time of purchase with your bike. This excludes items already marked down and some brands.

Service Plan
If you're local to Calgary or Canmore, you also get one complimentary complete tune-up within the first 16 months of owning the bike. Also included is a lifetime of unlimited service checks to keep you informed on the overall condition of your bike.

After Purchase Support
You're not on your own after you buy a bike from us. We have a dedicated e-comm team that is here to assist if you need help with anything. We also created video tutorials on how to unbox your bike when it arrives and get it ready to read.

Shipping & Returns

We care about your bike. We understand the excitement of unboxing a brand new bike and make sure you get the best experience when receiving your new bike.

Canadian shipping charges:

Sale bikes: $200
Standard pedal bikes over $1250: Free
Standard pedal bikes under $1250: $100
Electric bikes: $200
Fat bikes: $200
Kid's bikes: $60

Insurance charge: 1.5% insured value

We are currently offering gift cards to partially offset the price of shipping a bike! Visit our shipping page for more details

Cargo bikes:
Due to the size of the box that cargo bikes ship in, we are unable to ship cargo bikes directly to your address. Cargo bikes are shipped to a Manitoulin Depot for you to pick-up. For more detail, visit our shipping page.

Bike Specifications

Specifications are subject to change without notice

Drivetrain

Cassette Shimano Deore 10-51T 12spd

Chain Shimano M6100

Crankset Shimano Deore | 32T | 24mm Spindle | Crankarm Length: SM-MD = 165mm | L - XL = 170mm

Rear derailleur Shimano Deore 12spd

Shifter Shimano Deore 12spd

Brakes

Brakeset Tektro HD-M5141 | Shimano Pad Compatible

Cockpit

Grips tape ODI Elite Pro Lock On

Saddle WTB Volt 142 | Steel Rails

Stem Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm

Wheels

Front hub Shimano TC500 | 15mm Boost

Rear hub Shimano TC500 Boost 148mm

Rims WTB ST i30 TOUGH TCS 2.0 | 32H

Spokes 2.0 Stainless

Tires F: Maxxis Minion DHF 2.5 EXO Tubeless Ready | R: Maxxis Minion DHR II 2.4 EXO Tubeless Ready

Suspension

Fork Marzocchi Bomber Z 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset

Fork brand Marzocchi

Fork travel 170mm

Shock brand Marzocchi

Frame

Bottom bracket Shimano Threaded BBMT501-B

Description

RockShox Zeb RC, Fox Float X Performance, Shimano Deore 12spd

Charge harder. Go faster.

Purpose-built for speed. Demolish descents and hold bolder lines.

Completely reimagined, from the ground up.The all-new design makes the Altitude even faster than before. With increased stiffness and a lower centre of gravity, overall ride performance is leveled up.

Eats up tough terrain.Its finely tuned rate curve and concentrated suspension mass let it handle bumps effectively, keeping the rear wheel glued to the ground under power.

Ride support you can count on.The linear rate curve provides a supportive and predictable feel with minimal unwanted movement or harshness. Mid to large-sized impacts are absorbed effectively without compromising speed or control.

Geometry Chart

Shock Position

Wheel Size

Measurement	SM Pos 1 · 27.5"	SM Pos 2 · 27.5"	SM Pos 3 · 27.5"	SM Pos 4 · 27.5"	MD Pos 1 · 29"	MD Pos 2 · 29"	MD Pos 3 · 29"	MD Pos 4 · 29"	LG Pos 1 · 29"	LG Pos 2 · 29"	LG Pos 3 · 29"	LG Pos 4 · 29"	XL Pos 1 · 29"	XL Pos 2 · 29"	XL Pos 3 · 29"	XL Pos 4 · 29"	MD Pos 1 · MX	MD Pos 2 · MX	MD Pos 3 · MX	MD Pos 4 · MX	LG Pos 1 · MX	LG Pos 2 · MX	LG Pos 3 · MX	LG Pos 4 · MX	XL Pos 1 · MX	XL Pos 2 · MX	XL Pos 3 · MX	XL Pos 4 · MX
Reach (mm)	424	427	430	433	450	453	455	458	475	478	480	483	505	508	510	513	450	453	455	458	475	478	480	483	505	508	510	513
Stack (mm)	599	599	599	599	630	630	630	630	639	639	639	640	653	653	653	653	630	630	630	630	639	639	639	639	653	653	653	653
Head Tube Angle (°)	63°	63.3°	63.5°	63.8°	63°	63.3°	63.5°	63.8°	63°	63.3°	63.5°	63.8°	63°	63.3°	63.5°	63.8°	62.9°	63.2°	63.4°	63.7°	62.9°	63.2°	63.4°	63.7°	62.9°	63.2°	63.4°	63.7°
Seat Tube Angle (°)	77°	77.3°	77.5°	77.8°	77°	77.3°	77.5°	77.8°	77°	77.3°	77.5°	77.8°	77°	77.3°	77.5°	77.8°	77°	77.2°	77.4°	77.7°	77°	77.2°	77.4°	77.7°	77°	77.2°	77.4°	77.7°
Wheelbase (mm)	1189	1189	1188	1188	1244	1243	1243	1242	1283	1283	1282	1282	1319	1319	1319	1319	1243	1242	1242	1241	1282	1282	1281	1281	1319	1318	1318	1317
Head Tube Length (mm)	100	100	100	100	105	105	105	105	115	115	115	115	130	130	130	130	105	105	105	105	115	115	115	115	130	130	130	130
Seat Tube Length (mm)	365	365	365	365	410	410	410	410	440	440	440	440	470	470	470	470	410	410	410	410	440	440	440	440	470	470	470	470
BB Drop (mm)	24	20	17	13	38	34	31	27	38	34	31	27	38	34	31	27	29	25	22	18	29	25	22	18	29	25	22	18
Standover Height (mm)	760	763	765	768	792	794	796	798	798	801	803	806	809	812	814	817	791	793	796	798	797	801	803	806	808	812	814	817

Part Numbers

Size	Black/Black	Purple/White/Black
Small	SKUBALTA3027SMBK UPC770416015096 MPNBALTA3027SMBK	SKUBALTA3027SMPU VPNBALTA3027SMPU MPNBALTA3027SMPU
Medium	SKUBALTA3027MDBK UPC770416015072 MPNBALTA3027MDBK	SKUBALTA3027MDPU UPC770416016338
Large	SKUBALTA3027LGBK UPC770416015058	SKUBALTA3027LGPU UPC770416016314
X-Large	SKUBALTA3027XLBK UPC770416015119 MPNBALTA3027XLBK	SKUBALTA3027XLPU VPNBALTA3027XLPU MPNBALTA3027XLPU

Size Chart

Rocky Mountain Altitude Sizing

Size	Rider height (in)	Rider height (cm)
Small	5’0” - 5’6”	152.5 - 167 cm
Medium	5’4” - 5’10”	162.5 - 177.5 cm
Large	5’8” - 6’2”	172.5 - 188 cm
X-Large	6’0” - 6’6”	183 - 198 cm

2027 | Altitude A30
