RockShox
Vivid Coil Ultimate C1
Vivid Coil Ultimate C1
Regular price
$900.00
Sale price
$900.00
Regular price
Shipping calculated at checkout.
Couldn't load pickup availability
Shipping & Returns
Shipping & Returns
- Free shipping on orders over $80
- 100% satisfaction guaranteed. We stand behind everything that we sell. If for any reason you are not satisfied with your purchase, simply return the item within 30 days and we'll exchange it or refund your purchase.
Visit our shipping page for more details
SKU:140948-16
Share this product
Description
Description
Vivid Coil Ultimate is unmatched in downhill performance and tunability. Easily dial in the perfect ride feel with the TouchDown RC2T position-sensitive damper.
- TouchDown RC2T damper features sensitivity and suppleness off the top while remaining stable and supportive throughout its travel. Position-sensitive damper offers reliable performance and tunability with energetic responsiveness at every position in the travel.
- Rebound adjustment, independent High and Low Speed Compression adjustment, and an easy-to-adjust Threshold Lever for added pedaling efficiency.
- Adjustable Hydraulic Bottom Out has five compression settings at your fingertips to customize the amount of bottom-out resistance in the last 20% of travel.
- Soft, stroke-specific bottom-out bumper accommodates the range of stroke lengths, allowing for full travel.
- Spring sold separately
- SRAM Model ID: RS-VIVID COIL-ULTIMATE-C1
Attributes
| Damping | RC2T Adj. Hydraulic Bottom Out |
| Damping Adjustments | External rebound, 2 position (open/firm), HS&LS compression, Hydraulic Bottom Out |
| Primary Color | Black |
| Spring Adjustments | Preload |
| Spring Type | Coil |
Part Numbers
Part Numbers
| Mount / Options | 165 x 45 | 185 x 50 | 185 x 52.5 | 190 x 45 | 205 x 57.5 | 205 x 60 | 210 x 50 | 210 x 52.5 | 210 x 55 | 230 x 57.5 | 230 x 60 | 230 x 62.5 | 230 x 65 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Shaft Eyelet: Standard, Body Eyelet: Trunnion / Reb55/Comp30, Adj Hydraulic Bottom Out, Lockout 2 |
SKU140948-16
UPC710845910647
|
SKU140948-15
UPC710845910630
|
SKU140948-14
UPC710845910623
|
— |
SKU140948-12
UPC710845910609
|
— | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Trunnion / Reb25/Comp26, Adj Hydraulic Bottom Out, Lockout 2 | Transition Relay/Patrol 2022+ | — | — | — | — | — |
SKU140948-20
UPC710845910685
|
— | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Trunnion / Reb25/Comp34, Adj Hydraulic BottomOut, Lockout 2 | Specialized Enduro 2020+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Trunnion / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Bronson 4 2022+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Trunnion / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Megatower 2 2023+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Trunnion / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Nomad 6 2023+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Standard / Reb55/Comp30, Adj Hydraulic Bottom Out, Lockout 2 | — | — | — |
SKU140948-08
UPC710845910562
|
— | — |
SKU140948-07
UPC710845910555
|
SKU140948-06
UPC710845910548
|
SKU140948-05
UPC710845910531
|
SKU140948-04
UPC710845910524
|
SKU140948-03
UPC710845910517
|
SKU140948-02
UPC710845910500
|
SKU140948-01
UPC710845910494
|
| Shaft Eyelet: Standard, Body Eyelet: Standard / Reb25/Comp26, Adj Hydraulic Bottom Out, Lockout 2 | Transition Relay/Patrol 2022+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Standard / Reb25/Comp34, Adj Hydraulic BottomOut, Lockout 2 | Specialized Enduro 2020+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Standard / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Bronson 4 2022+ | — | — | — | — | — | — | — | — | — | — |
SKU140948-19
UPC710845910678
|
— | — |
| Shaft Eyelet: Standard, Body Eyelet: Standard / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Megatower 2 2023+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Standard, Body Eyelet: Standard / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Nomad 6 2023+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: No Bushing, Body Eyelet: Trunnion / Reb55/Comp30, Adj Hydraulic Bottom Out, Lockout 2 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: No Bushing, Body Eyelet: Trunnion / Reb25/Comp26, Adj Hydraulic Bottom Out, Lockout 2 | Transition Relay/Patrol 2022+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: No Bushing, Body Eyelet: Trunnion / Reb25/Comp34, Adj Hydraulic BottomOut, Lockout 2 | Specialized Enduro 2020+ | — | — | — | — | — |
SKU140948-21
UPC710845910692
|
— | — | — | — | — | — | — |
| Shaft Eyelet: No Bushing, Body Eyelet: Trunnion / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Bronson 4 2022+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: No Bushing, Body Eyelet: Trunnion / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Megatower 2 2023+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: No Bushing, Body Eyelet: Trunnion / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Nomad 6 2023+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Bearing, Body Eyelet: Standard / Reb55/Comp30, Adj Hydraulic Bottom Out, Lockout 2 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Bearing, Body Eyelet: Standard / Reb25/Comp26, Adj Hydraulic Bottom Out, Lockout 2 | Transition Relay/Patrol 2022+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Bearing, Body Eyelet: Standard / Reb25/Comp34, Adj Hydraulic BottomOut, Lockout 2 | Specialized Enduro 2020+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Bearing, Body Eyelet: Standard / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Bronson 4 2022+ | — | — | — | — | — | — | — | — | — | — | — | — | — |
| Shaft Eyelet: Bearing, Body Eyelet: Standard / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Megatower 2 2023+ | — | — | — | — | — | — | — | — | — | — | — |
SKU140948-18
UPC710845910661
|
— |
| Shaft Eyelet: Bearing, Body Eyelet: Standard / Reb55/Comp34, Adj Hydraulic Bottom Out, Lockout 2 | Santa Cruz Nomad 6 2023+ | — | — | — | — | — | — | — | — | — | — | — | — |
SKU140948-17
UPC710845910654
|
